Descrizione
| PRODUCT GROUP | (FC-) VLT® HVAC Drive FC- |
| SERIES | 102 |
| POWER RATING | (P2K2) 2.2 KW / 3.0 HP |
| PHASE | (T) Three phase |
| MAINS VOLTAGE | (4) 380 – 480 VAC |
| ENCLOSURE | (E20) IP20 / Chassis |
| RFI FILTER | (H2) RFI Class A2 (C3) |
| BRAKE – SAFE STOP | (X) No brake chopper |
| LCP (P/N: 131B3532) | (G) Graphical Loc. Cont. Panel |
| COATING PCB | (X) Not coated PCB |
| MAINS OPTION | (X) No Mains Option |
| ADAPTATION A | (X) Standard Cable Entries |
| ADAPTATION B | (X) No adaptation |
| SOFTWARE RELEASE | (SXXX) Latest release set. SW. |
| SOFTWARE LANGUAGE PACK | (X) Standard Language Pack |
| A OPTION | (AX) No A Option |
| B OPTION | (BX) No B Option |
| C0 OPTION MCO | (CX) No C0 option |
| C1 OPTION | (X) No C1 option |
| C OPTION SOFTWARE | (XX) No software option |
| D OPTION | (DX) No D option |
| FRAME SIZE (P/N: 131B3532) | A2 |
| TYPECODE PART 1 | FC-102P2K2T4E20H2XGX |
| TYPECODE PART 2 | XXXSXXXXAXBXCXXXXDX |
| PRODUCT CATALOG | (GLBL) Global (Standard) |
| VENDOR | (200010) Factory DK |
| RECOMMENDED PLANT | (B901) DK-G |
| CALCULATED GROSS WEIGHT | 4.535 |
| CALCULATED NET WEIGHT | 4.235 |
